The FC 21 refrigeration unit is a compact and easy-to-install unit capable of bringing temperatures down to -10°C. Thanks to a powerful internal fan, the fully portable unit guarantees a maximum airflow of 3,000 m3. A rugged frame protects the unit during use and an automatic thermostat adjusts the temperature to +/- 0.5 ° C. The FC 21 refrigeration unit is the ideal solution for all cold stores and temporary body storage.
Feature
down to -10 ° C
for deployment in noise-sensitive areas
for flexible deployment
ensuring low running costs
allowing simplified operation
enabling greater sustainability
affording customer peace of mind
facilitating use in any application
| Nominal cooling duty | 6.1 kW |
|---|---|
| Air flow (max) | 3,000 m3 /h |
| Power supply | 230 V 1 ph 50 Hz Run 24 A |
| Plug type | BS4343 230 V 32 A |
| Indoor noise level (max) | 55 dBA @ 3 metres |
| Outdoor noise level (max) | 65..1 dBA @ 1 metre |
| Indoor weight | 120 kg |
| Outdoor weight | 75 kg |
| Indoor dimensions (L x W x H) | 900 x 790 x 895 mm |
| Outdoor dimensions (L x W x H) | 700 x 680 x 670 mm |
| Control | Automatic thermostat |
| Average power consumption | 6.0 kW/h |
| Line length | 15 metres (max = 30 metres) |
| Operating temp range | -10ºC to +30ºC |
| Generator size | 12 kVA |
10M x 230V EXTENSION LEAD 4MM DIA
20M x 230V EXTENSION LEAD 4MM DIA
FASTCHILL 21 OUTDOOR UNIT
15M CONECTING LINES (MAX 2 SETS)
CONDENSATE HOSE
Cold stores
Fresh meat cold rooms
Temporary body storage
Archive document storage
Large volume air conditioning
Refrigerated warehouses
Beer cellars
Stand by for cold stores
Vegetable storage
Industrial processes
